Features

• 8 Channels Bi-Directional voltage translation

• No direction control required

• Translate between Ax and Bx automatically

• 3.3V and 5V input

How To Use

• Connect VCCA/VA to DC3.3V

• Connect VCCB/VB to DC5V

• Connect Both Power Source Negative To GND

• Connect I/O with 3.3V Level to Ax, then Bx will output 5V level

• Connect I/O with 5V Level to Bx, then Ax will output 3.3V level
