Features

• Using IRF520 Power MOSFET

• Output Load Voltage: 0 ~ 24V

• Output Load Current: < 5A (install heat sink if above 1A)

• Dimension: 33mm x 24mm

• *** Note: Install heat sink if load > 1A ***

Pin Definition

• GND : Connect to Ground

• VCC : Connect to 3.3V or 5V

• SIG : Digital input
